14
INSTALLATION INSTRUCTIONS
1
Remove the bottom two shipping bolts
with the wrench (included) to fully loosen
all four shipping bolts by turning them
counterclockwise and then pulling them out.
2
Locate the four hole caps included in the
accessory pack and install them in the
shipping bolt holes.
Unpacking and removing
shipping bolts
When removing the washer from the carton
base, be sure to remove the foam drum
support in the middle of the carton base.
If you must lay the washer down to remove
the base packaging materials, always lay it
carefully on its side.
DO NOT lay the washer on its front or back.
Shipping
bolt
Retainer
Cap
NOTE
Save the bolt assemblies for future use. To
prevent damage to internal components,
DO NOT transport the washer without
reinstalling the shipping bolts.
Failure to remove shipping bolts and retain-
ers may cause severe vibration and noise,
which can lead to permanent damage to
the washer. The cord is secured to the
back of the washer with a shipping bolt to
help prevent operation with shipping bolts
in place.
Foam Tub SupportCarton Base
Installing Hole cap
1
Take the hole cap out from manual bag.
2
Insert the hole cap (4 pieces) into hose
connect in back of the machine.
NOTE
In case of using auto dosing feature,
inserting hole cap is unnecessary.
Hole cap
