LG GD510 Service Manual

- 135 -
Copyright © 2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
13. EXPLODED VIEW & REPLACEMENT PART LIST
by SBOM standard on GCSC
Level
Location
No.
Description Part Number Spec Color Remark
2 AAAY00 ADDITION AAAY0397301 SILVER
3 MCJA00 COVER,BATTERY MCJA0095201 MOLD, PC LUPOY SC-1004A, , , , ,
SILVER
GRAY
I, 51
3 MMBB00 MANUAL,OPERATION MMBB0356702 PRINTING, (empty), , , , ,
WITHOUT
COLOR
2 APAY00 PACKAGE APAY0137304 GD510 UK (TR1-1HL/UK_UB/500ea)Packing
WITHOUT
COLOR
3 APLY00 PALLET ASSY APLY0003201 TDR TR1-1 STD Palletizing
Without
Color
4 MPBZ00 PAD MPBZ0219601 COMPLEX, (empty), , 503, 860, 145,
Without
Color
4 MPCY00 PALLET MPCY0013203 COMPLEX, (empty), , , , , BLUE
3 MBAD00 BAG,VINYL(PE) MBAD0005204 COMPLEX, (empty), , , , ,
WITHOUT
COLOR
3 MLAC00 LABEL,BARCODE MLAC0004541 PRINTING, (empty), , , , ,
Without
Color
3 MLAZ01 LABEL MLAZ0050901 PRINTING, (empty), , , , ,
WITHOUT
COLOR
2 APEY PHONE APEY0819601 SILVER
3 ACGM00 COVER ASSY,REAR ACGM0139301 SILVER G
4 MCCE00 CAP,RECEPTACLE MCCE0053401 COMPLEX, (empty), , , , , SILVER 49
4 MCJN00 COVER,REAR MCJN0107301 MOLD, PC LUPOY SC-1004A, , , , ,
SILVER
GRAY
44
4 MDAD00 DECO,CAMERA MDAD0049501 ELECTROFORMING, Ni, , , , ,
TITAN
GRAY
43
4 MPBT00 PAD,CAMERA MPBT0080901 COMPLEX, (empty), , , , ,
WITHOUT
COLOR
42
4 MPBU00 PAD,CONNECTOR MPBU0077401 COMPLEX, (empty), , , , ,
WITHOUT
COLOR
47
4 MPBU01 PAD,CONNECTOR MPBU0077501 COMPLEX, (empty), , , , ,
WITHOUT
COLOR
41
4 MSAZ00 SHEET MSAZ0057001 COMPLEX, (empty), , , , , BLACK 48
4 MTAB00 TAPE,PROTECTION MTAB0373001 COMPLEX, (empty), , , , , BLUE
4 MTAD00 TAPE,WINDOW MTAD0112501 COMPLEX, (empty), , , , ,
WITHOUT
COLOR
45
4 MWAE00 WINDOW,CAMERA MWAE0051001 CUTTING, PMMA MR 200, , , , , BLACK 46
3 ACGV00 COVER ASSY,BAR ACGV0009401 SILVER
13.2 Replacement Parts
Note: This Chapter is used for reference, Part order is ordered
<Mechanic component>

LG GD510 Specifications

General

Display type	TFT
Display diagonal	3 \
External display	No
Display resolution	240 x 400 pixels
Display number of colors	262144 colors
Internal memory	40 MB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	8 GB
Digital zoom	4 x
Rear camera resolution	2048 x 1536 pixels
Rear camera resolution (numeric)	3 MP
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Polyphonic rings quantity	64
Type	Feature phone
Product color	Silver
Talk time (2G)	3.3 h
Battery capacity	900 mAh
Standby time (2G)	360 h
Form factor	Bar
Phonebook capacity	1000 entries
Text prediction system type	T9
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, To-do list
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP
WAP	2.0
Data network	EDGE, GPRS
SIM card capability	Single SIM
Video call	-
Subscription type	No subscription
Specific absorption rate (SAR) value (EU)	- W/kg

Weight and Dimensions

Depth	11.2 mm
Width	49.5 mm
Height	97.8 mm
Weight	87 g
