2. PERFORMANCE
GD510 Operational Description Revision A
LG Electronics 10/112 LGE Property
2.2 Technical specification
Item Description Specification
1
Frequency Band
GSM900
TX: 890 + 0.2 x n MHz
RX: 935 + 0.2 x n MHz ( n = 1 ~ 124 )
EGSM
TX: 890 + 0.2 x (n-1024) MHz
RX: 935 + 0.2 x (n-1024) MHz ( n = 975 ~ 1023 )
DCS1800
TX: 1710 + ( n-511 ) u 0.2 MHz (n = 512 a 885)
RX: TX + 95 MHz
PCS1900
TX: 1850.2 + ( n-512 ) u 0.2 MHz (n = 512 a 810)
RX: TX + 80MHz
2
Phase Error
RMS < 5 degrees
Peak < 20 degrees
3
Frequency Error < 0.1ppm
GSM900/EGSM
Level Power Toler. Level Power Toler.
5 33 dBm ±2dB 13 17 dBm ±3dB
6 31 dBm ±3dB 14 15 dBm ±3dB
7 29 dBm ±3dB 15 13 dBm ±3dB
8 27 dBm ±3dB 16 11 dBm ±5dB
9 25 dBm ±3dB 17 9 dBm ±5dB
10 23 dBm ±3dB 18 7 dBm ±5dB
11 21 dBm ±3dB 19 5 dBm ±5dB
12 19 dBm ±3dB
DCS1800/PCS1900
Level Power Toler. Level Power Toler.
0 30 dBm ±2dB 8 14 dBm ±3dB
1 28 dBm ±3dB 9 12 dBm ±4dB
2 26 dBm ±3dB 10 10 dBm ±4dB
3 24 dBm ±3dB 11 8 dBm ±4dB
4 22 dBm ±3dB 12 6 dBm ±4dB
5 20 dBm ±3dB 13 4 dBm ±4dB
6 18 dBm ±3dB 14 2 dBm ±5dB
4
Power Level
7 16 dBm ±3dB 15 0 dBm ±5dB

LG GD510 Specifications

General

Display type	TFT
Display diagonal	3 \
External display	No
Display resolution	240 x 400 pixels
Display number of colors	262144 colors
Internal memory	40 MB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	8 GB
Digital zoom	4 x
Rear camera resolution	2048 x 1536 pixels
Rear camera resolution (numeric)	3 MP
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Polyphonic rings quantity	64
Type	Feature phone
Product color	Silver
Talk time (2G)	3.3 h
Battery capacity	900 mAh
Standby time (2G)	360 h
Form factor	Bar
Phonebook capacity	1000 entries
Text prediction system type	T9
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, To-do list
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP
WAP	2.0
Data network	EDGE, GPRS
SIM card capability	Single SIM
Video call	-
Subscription type	No subscription
Specific absorption rate (SAR) value (EU)	- W/kg

Weight and Dimensions

Depth	11.2 mm
Width	49.5 mm
Height	97.8 mm
Weight	87 g
