13. EXPLODED VIEW & REPLACEMENT PART LIST
by SBOM standard on GCSC
Level
Location
No.
Description Part Number Spec Color Remark
1 GSM,BAR/FILP TGSM0077201 SILVER
4 SNGF00 ANTENNA,GSM,FIXED SNGF0052302
3.0 ,-5.0 dBd,, ,internal, GSM850/900/DCS/PCS ,; ,QUAD
,-5.0 ,50 ,3.0
4 SACY00 PCB ASSY,FLEXIBLE SACY0100801 F_LCD C
5 SACB00
PCB
ASSY,FLEXIBLE,INSERT
SACB0058101
5 SACE00 PCB ASSY,FLEXIBLE,SMT SACE0091101
6 SACC00
PCB ASSY,FLEXIBLE,SMT
BOTTOM
SACC0066701
7 C801 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C802 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C803 CAP,CHIP,MAKER ECZH0000841 56 pF,50V ,J ,NP0 ,TC ,1005 ,R/TP
7 C804 CAP,CHIP,MAKER ECZH0003103 0.1 uF,10V ,K ,X7R ,HD ,1005 ,R/TP
7 C805 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 C806 CAP,CERAMIC,CHIP ECCH0000120 39 pF,50V,J,NP0,TC,1005,R/TP
7 C807 CAP,CERAMIC,CHIP ECCH0000115 22 pF,50V,J,NP0,TC,1005,R/TP
7 CN801
CONNECTOR,BOARD TO
BOARD
ENBY0036101 44 PIN,0.4 mm,ETC , ,H=1.0, Plug
7 CN802
CONNECTOR,BOARD TO
BOARD
ENBY0034201 24 PIN,0.4 mm,ETC , ,GB042 H=1.0, Socket
7 FB801 FILTER,BEAD,CHIP SFBH0009601
220 ohm,1005 ,DCR : 0.35 , Rated current :
500mA,PBFREE
7 L803 INDUCTOR,CHIP ELCH0005009 100 nH,J ,1005 ,R/TP ,
7 L804 INDUCTOR,CHIP ELCH0005009 100 nH,J ,1005 ,R/TP ,
7 Q801 TR,BJT,NPN EQBN0020501
ESM ,0.15 W,R/TP , ,; ,NPN ,5V ,60V ,50V ,150mA
,0.1uA MAX ,10 MIN 700 MAX ,100mW ,ESM ,R/TP ,3P
7 R801 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP
7 R802 RES,CHIP,MAKER ERHZ0000402 10 ohm,1/16W ,J ,1005 ,R/TP
7 VA801 VARISTOR SEVY0005202 5.5 V,+-30 ,SMD ,1005, 100 pF, Pb free
7 VA802 VARISTOR SEVY0003901
5.5 V, ,SMD ,Vdc 5.5, Vb 8, Cp 420, 1.0*0.5*0.6 , ,5.5 ,
,480 ,1.0*0.5*0.6 ,[empty] ,SMD ,R/TP
7 VA803 VARISTOR SEVY0005201 5.5 V, ,SMD ,1005, 50pF
7 VA804 VARISTOR SEVY0005201 5.5 V, ,SMD ,1005, 50pF
13.2 Replacement Parts
Note: This Chapter is used for reference, Part order is ordered
<Main component>

LG GD510 Specifications

General

Display type	TFT
Display diagonal	3 \
External display	No
Display resolution	240 x 400 pixels
Display number of colors	262144 colors
Internal memory	40 MB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	8 GB
Digital zoom	4 x
Rear camera resolution	2048 x 1536 pixels
Rear camera resolution (numeric)	3 MP
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Polyphonic rings quantity	64
Type	Feature phone
Product color	Silver
Talk time (2G)	3.3 h
Battery capacity	900 mAh
Standby time (2G)	360 h
Form factor	Bar
Phonebook capacity	1000 entries
Text prediction system type	T9
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, To-do list
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP
WAP	2.0
Data network	EDGE, GPRS
SIM card capability	Single SIM
Video call	-
Subscription type	No subscription
Specific absorption rate (SAR) value (EU)	- W/kg

Weight and Dimensions

Depth	11.2 mm
Width	49.5 mm
Height	97.8 mm
Weight	87 g
