- 65 -
Copyright © 2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
5. Trouble shooting
GD510 Operational Description Revision A
LG Electronics 70/113 LGE Property
5.6 Receiver & Speaker trouble
Check Points
-Speaker contact
-Audio amp soldering
1u
C205
C206 1u
1u
C208
8.2R202
27p
C210 C211
27p
R203 8.2
1u
C213
C215
1u
1uC223
MAX9877AEWP_TG45
U202
4C
3D
B4
D4
C3
B3
B5B2
D5C2
C1
D2
D1
A2
A1A5
A4
5C
1B
3A
SSV
DDV
D
DVP
C1N
C1P HPR
HPL
INA2
INA1
INB2
INB1 OUT+
BIAS OUT-
SDA
SCL
RXIN+
RXIN-
DNG
DNGP
1u
C214
220
MPZ1608S221A
FB201
VBAT
BB_SND_R
I2C_SDA
I2C_SCL
BB_SND_L
EAR_P
EAR_N
SPK_RCV_N
SPK_RCV_PFM_SND_L
FM_SND_R
HSO_R
HSO_L
22pF
C805
C806
39pF
VA803
EVLC5S0250
C807
22pF
VA804
EVLC5S0250
EME2012TP
CN804
2
1
SPK_RCV_P
SPK_RCV_N
Receiver & Speaker
