Page 6
Service Bulletin
Product: LED TV
Bulletin #: GLZ201900182-01
Release Date: 08/14/ 2019
[Repair Instruction] 3 of 4
4) Check attached SPCB EMI tape state in the square box
V_COM
Area
NG
OK
When the EMI tape Invades NG
Area, there is a risk of Screen
Whitening occurrence.
NG
The tape cross the NG area
OK
The tape doesn’t cross the NG area
Red line indicates border of V_COM pattern
* Please refer the printed letter “102”
on the board.
