Service Bulletin about Er IF, Frost build up on ice fan, Noise(Ice fan, grille fan, frost)
Service Bulletin
Applicable for Serial Number : 805TR** ~ 912TR** / 811KR** ~ 912KR**
1. Repair Instruction
※ SVC instruction for Er IF, Frost build up on ice fan, Noise(ice fan, Grille fan, Frost)
- Remove the grille fan in the freezer room, melt the ice built up around ice fan
- Replace the both gasket on the left door(assembled on right surface) with a foam applied one(SVC part).
- Replace the main PCB on the back of refrigerator.
Page 1
Applicable for models : LFXS26973S, LFXS26973D, LFXC22596S, LFXC22596D
Bulletin Type : SVC Notice Parts Others Applicable only with symptoms with every repair
Symptoms
Er IF, Frost build up on ice fan,
Noise(Ice fan, grille fan, frost)
Cause
Ice build up around Ice Fan after backflow of wet
air due to bad gasket sealing

Product : Ref
Bulletin # : CNZ201900500-01
Release Date : 2019.12.19


LG LMXS28596S Specifications

General

Type	freestanding
Style	french door; 4 door
Color	stainless steel
Total Capacity	27.6 cu. ft.
Refrigerator Capacity	18.4 cu. ft.
Freezer Capacity	yes; 9.2 cu. ft.
Humidity Controlled Crispers	2 humidity crispers
Defrost System	automatic
Cooling System	smart cooling plus™ system with door cooling+
Number of Refrigerator Shelves	4 (3-fixed, 1-fold)
Number of Refrigerator Door Bins	7
Number of Freezer Drawers	2-tier organization
Temperature Control	digital; yes
Temperature Sensor	6
Interior Light	ceiling led
Dispenser	external
Ice Maker	yes (dispenser)
Water Filter	lt1000p; yes
Door Alarm	yes
Smart Home	yes; smartthinq, google assistant, alexa
Remote Control	yes
Wi-Fi	yes
Annual Energy Consumption	760 kwh/year
Voltage	120 volts
Current	15

Weight and Dimensions

Depth	36 1/4 inch
Height	69 3/4 inch
Width	35 3/4 inch
Net Weight	322 lbs.
