114
APPENDIX
APPENDIX
■ The specifications shown above may be changed without prior notice for quality improvement.
<M2280D>
LCD Panel
Screen Type
546.86 mm Wide (21.53 inch) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 546.86 mm
Pixel Pitch
0.248 mm (H)x0.248 mm (V)
Video Signal
Max. Resolution
1920x1080 @ 60 Hz
Recommended Resolution
1920x1080 @ 60 Hz
Horizontal Frequency
30 kHz to 83 kHz
Vertical Frequency
56 Hz to 75 Hz
Synchronization Type
Separate Sync, Digital
Input Connector
TV, D-Sub Analog, PC Audio In, component, HDMI
*
2, CVBS
Power
Rated Voltage
19 V 2.2 A
Power Consumption
On Mode 35 W (typ.)
Off Mode ≤ 1 W
AC/DC Adapter
Manufacturer: LITE-ON, Model PA-1650-68
INPUT: AC 100-240 V 50/60 Hz 2.0 A
OUTPUT: DC 19 V / 3.42 A
Tilt Tilt Range
-5° to 10°
Dimensions (Width x Height x Depth)
Weight
M2280D
509.6 mm x 396.2 mm x 193.8 mm (20.06 inch x 15.6 inch x 7.63 inch)
3.7 kg (8.16 lb)
Environmental
Conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Storage Temperature
Storage Humidity
