EXTERNAL EQUIPMENT SETUP
ANTENNA CONNECTION
■ To prevent damage do not connect to the mains outlet until all connections are made between the devices.
■ For optimum picture quality, adjust antenna direction.
■ An antenna cable and converter are not supplied.
Multi-family Dwellings / Apartments
(Connect to wall antenna socket)
Wall
Antenna
Socket
Outdoor
Antenna
Single-family Dwellings / Houses
(Connect to wall jack for outdoor antenna)
RF Coaxial Wire (75 Ω)
■ In poor signal areas, to get better picture quality, install a signal amplifier to the antenna as shown above.
■ If signal needs to be split for two sets, use an antenna signal splitter for connection.
EXTERNAL EQUIPMENT SETUP
Antenna
Signal
Amplifier
UHF
VHF
To Next Page
