Linksys LAPAC1750 User Manual

Time
Current Time
Display current date and time of the system.
Manually
Set date and time manually.
Automatically
When enabled (default setting) the access point will get the
current time from a public time server.
Time Zone
Choose the time zone for your location from the drop-down
list. If your location observes daylight saving time, enable
“Automatically adjust clock for daylight saving changes.”
Start Time
Specify the start time of daylight saving.
End Time
Specify the end time of daylight saving.
Offset
Select the adjusted time of daylight saving.
NTP
NTP Server 1
Enter the primary NTP server. It can be an IPv4 address or a
domain name.
Valid characters include alphanumeric characters, "_", "-"
and ".". Maximum length is 64 characters.
NTP Server 2
Enter the secondary NTP server. It can be an IPv4 address
or a domain name.
Valid characters include alphanumeric characters, "_", "-"
and ".". Maximum length is 64 characters.
Log Settings
Go to Configuration > Administration and select Log Settings to configure logs. Logs record
various types of activity on the access point. This data is useful for troubleshooting, but enabling
all logs will generate a large amount of data and adversely affect performance.
14

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
