Linksys LAPAC1750 User Manual

MAC Address
MAC address of the client.
IP Address
IP address of the client.
User Name
User name used by the client to log in.
SSID Name
Name of the SSID to which the client is connected.
Online Time
How long the client has been online. Measured in
seconds.
Away Timeout
An authenticated client that has been disconnected
from the access point has a specific amount of time
within which it may reconnect without re-
authentication. The timer starts when the client
disconnects from the SSID. After the time reaches
zero, the client is de-authenticated. If the timeout is
set to 0, the client is not de-authenticated. Measured
in seconds.
Session Timeout
The remaining time of the authenticated session. The
timer starts when the client is authenticated. After
the time reaches zero, the client is de-authenticated.
If the value is fixed to 0, the session won't time out.
Measured in seconds.
Cluster
The cluster function provides a centralized method to administer and control wireless services
across multiple devices. When access points are clustered, you can view, deploy, configure, and
secure the wireless network as a single entity.
Note- Firmware version 1.1.0 or above support cluster feature. If your device has legacy firmware
installed, download the latest one from www.linksys.com/support
.
The access points within a cluster must have the same management VLAN configured. A cluster
can support 16 LAPAC1750 access points as long as they are same model number.
In each cluster, one access point must be manually configured as the master access point. There
can only be one master in a cluster. This master will propagate configuration information, such as
wireless settings, time settings etc. to the other team members within a cluster. Log in to the
master access point to change sharable parameter settings instead of slaves.
72

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
