Linksys LAPAC1750 User Manual

Authentication Server
Primary Server
Enter the IP address of the RADIUS Server on your
network.
Primary Server Port
Enter the port number used for connections to the
RADIUS Server. It is a value from 1 to 65534, and
default is 1812.
Primary Shared
Secret
Enter the key value to match the RADIUS Server. It
consists of 1 to 64 characters.
Backup Server
The Backup Authentication Server will be used when
the Primary Authentication Server is not available.
Backup Server Port
Enter the port number used for connections to the
Backup RADIUS Server. It is a value from 1 to 65534,
and default is 1812.
Backup Shared
Secret
Enter the key value to match the Backup RADIUS
Server. It consists of 1 to 64 characters.
Rogue AP Detection
Go to Configuration > Wireless > Rogue AP Detection to detect the unexpected or unauthorized
access point installed in a secure network environment.
40

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
