Linksys LAPAC1750 User Manual

Band Steering
Band Steering
Enable or disable Band Steering function.
Band Steering is a technology that detects whether
the wireless client is dual-band capable. If it is, band
steering pushes the client to connect to the less-
congested 5 GHz network. It does this by actively
blocking the client’s attempts to connect with the
2.4GHz network.
Isolation
Isolation between
SSIDs
Define whether to isolate traffic between SSIDs. If
enabled, wireless clients in different SSIDs cannot
communicate with each other. Enabled by default.
Advanced Parameters
Wireless Radio
Select the desired radio from the list.
Radio 1 is for 2.4 GHz, and Radio 2 is for 5 GHz.
Worldwide Mode
(802.11d)
Worldwide Mode (802.11d) enables the access point
to direct connected wireless devices to radio settings
specific to where in the world the devices are in use.
Channel Bandwidth
Select the designed channel bandwidth for the
wireless radio.
20MHz - Select if you are not using any 802.11n
wireless devices.
20/40MHz - Select if you are using both 802.11n and
non-802.11n wireless devices.
20/40/80MHz - Select if you are using 802.11ac,
802.11n and non-802.11n wireless devices.
Guard Interval
Select the guard interval manually for Wireless-N
connections. The two options are Short (400
nanoseconds) and Long (800 nanoseconds). The
default is Auto.
58

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
