Lippert Components Solera Classic User Manual

13
lci1.com 574 - 537- 890 0 Rev: 11.16.18
Solera
®
Classic Awning
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001254
What is Happening? What Should Be Done?
Awning will not extend.
Check position of the cam lock (extend) roll out.
Ensure that the travel locks have been released from the outer arm.
Make sure the locking knob for the rafters has been loosened.
Check to see if the outer arm is resting on the mount/rafter arm.
If so, the outer arm height adjustment is not set properly.
Awning will not retract or
only retracts part way.
Make sure the mount/rafter arms have been put in the stored position and the locking
knob has not been tightened.
Check position of cam lock (retract) roll in.
Ensure the outer arms have been placed in the closed/stored position.
Ensure the awning has the proper tension on it.
Ensure that the mount/rafter arm is not secured to the head
of the outer arm.
Fabric is loose or sags
on the edges and
middle.
Make sure the mount/rafter arms have been put in the stored position and the locking
knob has not been tightened.
Check position of cam lock (retract) roll in.
Ensure the outer arms have been placed in the closed/stored position.
Ensure the awning has the proper tension on it.
Ensure that the mount/rafter arm is not secured to the head of the outer arm.
Locking knob will not
tighten.
The nut for this is a thread part that tightens the arms together.
Open the awning and check when turning the knob that the nut is not stripped out. If it is
not stripped, it would require replacing both parts.
Mount/rafter arm will not
extend.
Make sure the locking knob has been loosened.
Make sure there is no debris in the track the arm slides in.
Make sure arm is not bent.
Awning will not roll up
straight.
Check to make sure fabric is centered on roll tube and also centered between the arms
attached to the unit.
If the fabric is not centered, move the screws on both ends of the awning and shift the
fabric accordingly.
Make sure there are screws at both ends of the fabric securing it to the roll tube and at
the awning rail. If there is only one screw at one end and not the other, the awning may
not roll up correctly.
Make sure the legs are square and straight.
Awning will not stay in
the rolled out position.
Check the cam lock. Signs of a faulty cam lock include:
The absence of a clicking noise when the awning is rolled out.
The awning rolling back up after it is placed in the stop position.
Troubleshooting chart
