19
1. To connect to a mains power supply of 220-240V~, follow the instructions below:
a. Unscrew the cable bracket.
b. Connect the LIVE wire to L.
c. Connect the NEUTRAL wire to N.
d. Connect the EARTH wire (normally yellow/green) to the EARTHING
connector.
e. Replace the cable bracket and screw securely into place.
Always place the wire on the side of the screw which follows the tightening direction
(clockwise).
• If the mains cable is damaged and needs to be replaced, this should be done by a
qualied person using the proper tools, so as to avoid any accidents.
• If the ceramic hob is being connected directly to the mains supply, an omnipolar circuit
breaker must be installed with a minimum gap of 3mm between the contacts.
• The installer must ensure that the correct electrical connection has been made and that
it complies with safety regulations.
• The mains cable must not be bent or compressed.
• The mains cable must be checked regularly and only replaced by a qualied person.
2. After all connections are thoroughly checked and secure, replace the Terminal Box cover.
Snap the cover back on. Ensure it is secure.
Wiring Instructions
This connection is only for cables 4mm
2
–
6mm
2
thick.
LBMFMX15_IB_RC_160920_grace.indd 19 20/9/16 5:53 pm
