Lombardini LDW 1003 Repair Manual

COMPILER TECO/ATL
REG. CODE
1-5302-351
MODEL N°
50563
DATE OF ISSUE
04.90
REVISION 04
ENDORSED
DATE
15.11.99
13
GENERAL
I
POWER RATINGS FOR LDW-FOCS GENSET SPEC
DIESEL ENGINES
CONTINUOUS (NA) RATING- kW
ENGINE 1500 1800 3000 3600
MODEL r/min r/min r/min r/min
LDW 602 4.5 5.4 9.0 9.9
LDW 903 6.7 8.1 14.0 14.9
LDW 1204 9.0 10.8 18.9 19.9
LDW 1204/T 11.7 14.0 24.8 25.8
LDW 702 5.0 5.9 9.9 10.6
LDW 1003 7.7 9.0 14.9 16.3
LDW 1404 9.9 11.7 19.8 22.8
NOTE: THE ABOVE RATINGS ARE FLYWHEEL OUTPUT, NOT ELECTRICAL GENSET OUTPUT
INTERMITTENT (NB) RATING- kW
ENGINE 1500 1800 3000 3600
MODEL r/min r/min r/min r/min
LDW 602 5.0 6.0 10.0 11.0
LDW 903 7.5 9.0 15.5 16.5
LDW 1204 10.0 12.0 21.0 22.0
LDW 1204/T 13.0 15.5 27.5 28.5
LDW 702 5.5 6.5 11.0 11.7
LDW 1003 8.5 10.0 16.5 18
LDW 1404 11.0 13.0 22.0 25
NOTE: THE ABOVE RATINGS ARE FLYWHEEL OUTPUT, NOT ELECTRICAL GENSET OUTPUT
POWER RATING STANDARDS
NB- ISO 3046/1-IFN - Maximum intermittent rating with no overload capacity; operation with constant speed and variable load.
NA- ISO 3046/1-ICXN- Continuous rating with 10% intermittent overload allowed; operation with constant speed and constant load.
Standard Rating Conditions: 25°C, 100kPa Total Barometric Pressure, 30% Relative Humidity.
Standard Production Power Tolerance = +/- 5%
Standard/ General Derations: 2% per 5°C increase in temperature over 25°C; 1% per 100m over mean sea level

Lombardini LDW 1003 Specifications

General

Number of Cylinders	3
Cooling System	Water-cooled
Power Output	18.5 kW (25 hp) at 3000 rpm
Fuel System	Indirect injection
Fuel Type	Diesel
Engine Type	Diesel, 4-stroke
Starting System	Electric
Displacement	1028 cm³ (62.7 in³)
Bore x Stroke	75 x 77.6 mm (2.95 x 3.06 in)
