necessarily be routed to any physical outputs (see Patchbay/Router Page). On the
Mac, these inputs are labeled “SM/ASIO,” as these software streams will be
receiving their digital audio either from the Sound Manager or the ASIO driver,
depending on your selection.
Further to the right are more channels, labeled "H/W In S/PDIF" and "H/W In
1/2" through "H/W In 7/8." These mixer inputs are audio streams from the
physical Delta 1010 hardware inputs, hence the "H/W" at the front of each label.
These labels are consistent on both the Mac and PC.
PAN: Each mixer input may be individually panned anywhere in the stereo
output mix. A pan control is positioned directly under each input channel peak
meter and has the appearance of a small vertical pointer. To make a coarse
adjustment, click on the pan control with your mouse and drag it to the desired
position. For finer adjustment (in 1% increments), you may click on the pan
control to make it active, and then use the left/right or up/down cursor keys on
your computer keyboard. Either way, while the pan setting is being adjusted, its
value will appear numerically in the Master Volume’s status box (below the
Master Volume Stereo Gang control) as a percentage from left pan to right pan:
-100% represents far left, +100% represents far right, and 0% represents the
center.
SOLO: Each mixer input channel has a "Solo" checkbox associated with it.
Clicking on and activating a Solo box will solo the selected channel by
essentially muting all other signals. When more than one channel has Solo
selected, all solo channels will be summed to the solo ‘buss’ (path), which is
what one might consider an ‘in place’ solo as opposed to a PFL, or pre-fader
listen (levels and pans still apply). Deactivating all solo boxes will return all
input channels to their previous mute/unmute states.
MUTE: Every mixer input channel has a "Mute" checkbox associated with it.
Clicking on and activating the Mute box will remove that signal from the stereo
buss. Deactivating the Mute box will add the signal back into the stereo buss.
STEREO GANG: All input channel pairs have a "Stereo Gang" capability.
Clicking on and activating the Stereo Gang checkbox will link (or "gang") the
left/right faders so that both channels may be adjusted together as a stereo pair.
Patchbay/Router Page
The Patchbay/Router page allows you to connect each of the Delta 1010’s
hardware outputs (4 pairs of analog outputs and 1 pair of digital output channels)
to specific audio sources within the Delta 1010 board. To display this page, click
the "Patchbay/Router" tab of the Delta Control Panel.
ON THE MAC: Please substitute the name “SM/ASIO” where referrences are
20
