loosely over it with the card in the upright position. Press the card gently but
firmly downward into the slot until the card is completely and squarely
seated in the slot. If the card seems difficult to seat, a slight rocking motion
may help.
7. Screw the Delta 1010 PCI host card’s metal bracket down into the screw hole
on the back of your computer using the screw you removed in step 5 above.
8. Place the cover back on your computer.
IMPORTANT: Complete the attachment of your Delta 1010 rack
mount unit and its 9v power supply to the PCI card before powering
up your computer. Never attach the rack unit to the PCI card while
the computer is on. Doing so could damage the PCI card and void
the warranty.
Now it is time to connect the Delta 1010 rack-mount unit to the PCI host card
that you have just installed. With your computer turned off:
1. Mount the Delta 1010 rack-mount unit in your rack, or place it on a desktop
in a convenient but secure place.
2. Connect one end of the supplied host cable to the 25-pin D-sub connector on
the rack mount unit.
3. Connect the other end of the host cable to the 25-pin D-sub connector on the
Delta 1010 PCI Host card that now resides in your computer.
4. Connect the appropriate end of the 9V AC power supply into the wall outlet
to supply standard house current. Plug the other end into the Delta 1010 9V
AC power jack.
Delta Driver Software Installation
The Delta 1010 system includes a driver CD for Windows 98/95/NT and
Macintosh, containing all Windows drivers, Macintosh drivers (including all
ASIO and MIDI), and Delta Control Panel software. To install these on your
system, please follow these steps:
Windows 98 Installation
1. After installing the Delta 1010 hardware, boot your system and start
Windows. During the Windows boot procedure, new hardware will be
automatically detected by the Add New Hardware Wizard as shown here.
Click ‘Next>’.
6
