ENGINE COMPARTMENT FUSE/RELAY BOX
LOCATION – LEFT FENDER
C78
60A
1
HEAD LAMP
LOW BEAM
20 A
HEAD LAMP
HIGH BEAM
20 A
15A
6
25A
7
15A
9
15A
8
15A
10
100A
12
30A
5
HORN
20 A
60A
2
40A
3
30A
4
FRONT
FOG
20 A
ENGINE COMPARTMENT FUSE/RELAY BOX - FUSES/CIRCUITS/RATINGS
FUSE
No
FUSE
RATING
COLOUR
CIRCUIT
FUSE No
FUSE
RATING
COLOUR
CIRCUIT
1
60A
YELLOW
MAXI FUSE 1
7
25A
WHITE
ABS
2
60A
YELLOW
MAXI FUSE 2
8
15A
BLUE
HEADLAMP - HIGH
3
40A
GREEN
ABS
9
15A
BLUE
HEADLAMP - LOW
4
30A
PINK
ECU
10
15A
BLUE
HORN
5
30A
GREEN
REAR BLOWER
11
6
15A
BLUE
FRONT FOG
12
100A
BLUE
CHARGING SYSTEM
NA FOR
H4
MODEL
A
PPLICABLE
FOR ONLY ABS
MODEL
APPLICABLE
FOR ONLY ABS
MODEL
NA FOR H4
MODEL
ENGINE COMPARTMENT FUSE / RELAY BOX
