The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the manufacturer in the production of the various component
units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present document,are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any
person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd.,will amount to unauthorized use and shall be liable for penalty/prosecution© 2013 Mahindra & Mahindra Ltd.
MAN-00233
MAY 2013/Rev 1
WIRING MANUAL
25042013
ELECTRICAL SYMBOLS USED IN WIRING CIRCUITS
Bi-filament lamp
Coil
Solenoid controlled valve
or clutch solenoid
Transistor
Lamp
Symbols
Illustration Description
Ground
Female connector
Male connector
12
Inter-Harness Connector
To Next Page
