WIRING MANUAL
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction,
translation, transmission, in part of or whole of the present document,are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd.,will amount to unauthorized use and shall be liable for penalty/
prosecution© 2013 Mahindra & Mahindra Ltd.
MAN-00233
MAY 2013/Rev1
25042013
1
C109
Y 1.0
2
0
1
03 04
1
LC193
Roof Lamp
Front
0) Off
1) Permanently On
2) Auto Position
(On withany Door Open)
3) Map Reading Lamp On
4) Map reading Lamp On
1
2
R-Y 0.5
B 0.5
5
15
10A
F19
LC103
IP FUSE
BOX
Y 1.5
Y 1.0
1
C60
R 6.0
R 6.0
2
Y 1.0
C403
Y 0.75
C103
C103
C194
C193
C403
4
19
C109
C100
11
LC100
MBFM-22P
R-Y 0.5
R-Y 0.5
R-Y 0.5
R-Y 0.5
6
C403
G24
1
C372
Y 1.0
Y 1.0
0) Off
1) Permanently On
2) Auto Position
(On withany Door
Open)
1
C380
C381
B 0.5
B 1.0
B 1.0
B 4.0
1
R-Y 0.5
R-Y 0.5
13
C372
C372
4
4030
1
0
2
G24
2
LC380
Roof Lamp
Rear
Y 0.5
1
2
LC382
MAP
READING
LAMP LH
1
2
B 0.5
B 0.5
C382
C382
C383
C383
LC383
MAP
READING
LAMP RH
G2
LC78
ENGINE
ROOM FUSE
BOX
B 16.0
100A
F1
R 16.0
-
+
BATT
12V
60A
F5
G1
C324
1
C73
C78
31
Y 0.5 Y 0.5
B 4.0
R 4.0
INTERIOR LIGHTING
APPLICABLE MODELS: H4/H4 ABS
91
