The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the manufacturer in the production of the various component
units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present document,are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any
person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd.,will amount to unauthorized use and shall be liable for penalty/prosecution© 2013 Mahindra & Mahindra Ltd.
MAN-00233
MAY 2013/Rev 1
WIRING MANUAL
25042013
TERM
POSITION
LOCK KEY OUT
LOCK KEY IN
OFF
IGNITION
START
POSITION
TERM
30
KA
KA
LC113
IGNITION
SWITCH
30
15a 15P50
P 15a 15 50
LC252
Cluster 32F
16
16
C59
GR-B 0.5
1
1
C52
LC44
Alternato
R 16.0
5
MAIN
DIODES
STATOR
REGULATOR
ROTOR
DIODES
AUX.
LC101
MBFM 12P
5
GR-B 0.5
GR-B 0.5
GR 0.5
GR 1.0
1
W 2.5
10A
F48
35
45
LC103
IP FUSE
BOX
Y 4.0
Y 6.0
C60
2
Y 6.0
R 16.0
GR-B 0.5
MBFM 12P
C44
C101
C252
C252
C103
C103
C113
1
C113
G2
LC78 ENGINE
ROOM FUSE
BOX
B 16.0
100A
F1
KL30
R 16.0
-
+
BATT
12V
60A
F4
G1
C374
2
C73
C78
31
CHARGING CIRCUIT
APPLICABLE MODELS: H4/H4 ABS / H8 /H8 AIR BAG / H9
To Next Page
