Hydraulic Specification & Torque Values
Hydraulic Specifications
The Pump
Make Dowty
Type Gear
Capacity (cc/rev) 7.03
Output @ 2300 Engine RPM (lpm) 16
Control Valve
Make M & M
Relief Valve Pressure (kg/sqcm) 123 - 157
Lift Cylinder (mm) 76.2
Rock Shaft
Rockshaft OD (mm) 46.95 - 46.91
Bush ID (mm) 47.03 - 46.98
Bell Crank
Bell Crank Pin (mm) 20.00 - 19.9
Sr No Description Torque (Nm)
1 Closure Plate to VTU Bolt 45 to 50
2 Mounting Bolts 18 to-20
3 Bell crank to DC Outer Rod Bolt 18 to 20
4 Quadrant Tightening Bolt 20 to 25
5 Quadrant Mounting Bolts 35 to 40
6 Control Valve Mounting Bolts 95 to 101
7 Draft Sensing Bolts 96 to 102
8 Hydraulic Mounting Bolts 41 to 45
9 Hydraulic Mounting Studs 55 to 60
10 Hydraulic Mounting Nut 41 to 45
11 DC Sensing Nut 15
12 DC Sensing Lock Nut 25
