78
29
27
25
24
23
21
18
16
15
14
28
26
22
19
1
29
27
25
24
23
21
19
28
26
22
20
17
6
7
8
5
33
15
16
30
14
2
11
10
12
13
11
13
12
3
5
4
4
31
14
32
9
32
14
Sr. No. Description
1 Support Front Axle
2 Axle Front Complete
3 washer Thrust Front Axle Support 4.5
4 ‘O’ Ring Pivot Pin Sleeve
5 Bush Pivot Pin Sleeve
6 Pin Pivot Cpte
7 Bolt Pivot Pin
8 Washer Spring Lock
9 Arm Knuckle LH
10 Arm Knuckle RH
11 Bolt M12
12 Wahser Spring Lock
13 Nut M12
14 Bush King Pin Sleeve
15 Washer Cast Iron
16 Seal Oil King Pin Sleeve
17 Knuckle Steering Cpte LH
Sr. No. Description
18 Knuckle Steering Cpte RH
19 V Seal Front Wheel Hub
20 Dust Shield
21 Seal Oil Front Wheel Hub
22 Spacer Inner Bearing
23 Bearing Inner Front Wheel Hub
24 Hub Front Wheel
25 Bearing Outer Front Wheel Hub
26 Washer Outer Bearing Retainer
27 Nut Slotted
28 Pin Split
29 Cap Front Wheel Hub
30 Nipple Grease
30 Nipple Grease
31 Key Wood Ruff
32 ‘O’ Ring King Pin Sleeve
33 Washer Thrust Front Axle Support 2.5
Front Axle & Support
