SU1000C/SERVEND UC-300 DISPENSER/CVD1075
REMOTE AIR COOLED
NOTE: These characteristics may vary depending on
operating conditions.
CYCLE TIMES
24-HOUR ICE PRODUCTION
OPERATING PRESSURES
Freeze Time + Harvest Time = Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10.0 70/21.1 90/32.2
-20 to 70/
-29 to 21.1
9.9-10.6 10.8-11.6 11.8-12.6
.75-2.5
80/26.7 10.1-10.9 10.9-11.7 12.1-13.0
90/32.2 10.6-11.4 11.5-12.3 12.8-13.7
100/37.8 11.6-12.5 12.6-13.5 14.0-15.0
1
Times in minutes.
Air Temp.
Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10.0 70/21.1 90/32.2
-20 to 70/
-29 to 21.1
980 910 840
80/26.7 960 900 820
90/32.2 920 860 780
100/37.8 850 790 720
1
Based on average ice slab weight of 7.75-8.25 lb.
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
psig
Suction
Pressure
psig
Discharge
Pressure
psig
Suction
Pressure
psig
-20 to 50/
-29 to 10.0
260-215 40-22 140-185 70-95
70/21.1 270-220 42-24 150-190 80-95
80/26.7 275-225 48-24 155-195 85-95
90/32.2 275-235 52-25 165-195 85-100
100/37.8 325-260 55-25 180-205 85-112
110/43.3 360-300 60-27 195-225 95-118
Refer to page 176.
