Manitowoc CVD1475 User Manual

–182–
Q1400C/CVD1476 REMOTE WATER COOLED
NOTE: These characteristics may vary depending on
operating conditions.
CYCLE TIMES
24-HOUR ICE PRODUCTION
OPERATING PRESSURES
CONDENSER WATER CONSUMPTION
Freeze Time + Harvest Time = Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10.0 70/21.1 90/32.2
35 to 70/
1.6 to 21.1
10.7-12.7 12.4-14.7 14.6-17.3
.75-2.5
80/26.7 10.8-12.9 12.5-14.9 14.7-17.4
90/32.2 10.9-13.0 12.6-15.0 14.8-17.5
100/37.8 10.9-13.0 12.7-15.0 14.9-17.6
1
Times in minutes.
Air Temp.
Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10.0 70/21.1 90/32.2
35 to 70/
1.6 to 21.1
1420 1245 1070
80/26.7 1400 1230 1065
90/32.2 1395 1225 1060
100/37.8 1390 1220 1055
1
Based on average ice weight of one Harvest cycle 12.00-14.00 lb.
(6.00-7.00 lb. per evaporator).
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
psig
Suction
Pressure
psig
Discharge
Pressure
psig
Suction
Pressure
psig
35 to 70/
1.6 to 21.0
265-235 48-28 150-170 70-90
80/26.7 265-235 48-28 150-170 70-90
90/32.2 265-235 48-28 150-170 70-90
100/37.8 270-235 49-29 160-180 70-90
110/43.3 275-235 50-30 160-180 75-95
Refer to page 176.
Condenser
Water
Consumption
90/32.2 Air Temperature Around Ice Machine
Water Temp. °F/°C
50/10.0 70/21.1 90/32.2
Gal/24 Hours 1200 2100 4000

Manitowoc CVD1475 Specifications

General

Model	CVD1475
Type	Ice Maker
Production Capacity	1475 lbs per day
Weight	250 lbs
Condenser Type	Air-Cooled
Voltage	208-230V
Daily Ice Production	1475 lbs
Refrigerant	R404A
