–174–
QUIETQUBE
®
TUBING SCHEMATICS
Q0600C/Q0800C/Q1000C
RECEIVER
RECEIVER
SERVICE
VALVE
LLSV
SUCTION
SHUT-OFF
VALVE
HEAT EXCHANGER
CHECK VALVE
HEAD PRESSURE
CONTROL VALVE
ACCUMULATOR
TXV
COOL VAPOR VALVE
COMPRESSOR
EVAPORATOR
LIQUID LINE
SHUT-OFF
VALVE
CONDENSER
S TRAP
REQUIRED
21’ OR
GREATER
RISE
DRIER
SUCTION
LINE FILTER
Ice Machine Head Section
Condensing Unit
