Manitowoc RFS1200 User Manual

210 Part Number 000007661 11/16
RNS0609W
WATERCOOLED
Characteristics will vary depending on operating
conditions.
ICE PRODUCTION
Air Temperature
Water Temperature
24 Hour
Ice Production
70°F/50°F
21°C/10°C
613 lbs
278 kgs
90°F/70°F
32°C/21°C
508 lbs
230 kgs
OPERATING PRESSURES PSIG/kPa
Air Temperature
Around Ice Machine
°F/°C
Freeze Cycle
Discharge
Pressure
Suction
Pressure
70°F PSIG
21°C kPa
235-245
1670-1689
27-29
186-199
90°F PSIG
32°C kPa
235-245
1670-1689
27-29
186-199
110°F PSIG
43°C kPa
240-260
1655-1793
28-32
193-220
Condenser Water Consumption @ 80°F/70°F
109 Gallons/100 lbs. of Ice
413 Liters/45 kgs. of Ice
Water regulating valve set to maintain 240 PSIG - 1655 kPa
