264 Part Number 000007661 11/16
Refrigeration Tubing Schematics
Flake Models
RF0244/RFS0244/RF0266/RF0300/RF0385/RF0388/
RF0399/RF0644/RF0650
1
2
3
4
5
6
7
TUBING DIAGRAM LEGEND
1 Compressor
2 Condenser
3 Liquid Line Drier
4 Capillary tube
5 Accumulator
6 Heat Exchanger
7 Evaporator
