Manitowoc RFS1200 User Manual

212 Part Number 000007661 11/16
RNS1009W
WATERCOOLED
Characteristics will vary depending on operating
conditions.
ICE PRODUCTION
Air Temperature
Water Temperature
24 Hour
Ice Production
70°F/50°F
21°C/10°C
1158 lbs
525 kgs
90°F/70°F
32°C/21°C
960 lbs
435 kgs
OPERATING PRESSURES PSIG/kPa
Air Temperature
Around Ice Machine
°F/°C
Freeze Cycle
Discharge
Pressure
Suction
Pressure
70°F PSIG
21°C kPa
235-245
1670-1689
29-31
200-214
90°F PSIG
32°C kPa
235-245
1670-1689
29-31
200-214
110°F PSIG
43°C kPa
240-260
1655-1793
30-36
207-248
Condenser Water Consumption @ 80°F/70°F
131 Gallons/100 lbs. of Ice
496 Liters/45 kgs. of Ice
Water regulating valve set to maintain 240 PSIG - 1655 kPa
