STEP 1 | PAD ASSEMBLY INSTRUCTIONS & NOTES
ASSEMBLY
PART 9: PAD ASSEMBLY
ID DESCRIPTION QUANTITY
4 M10 Flat Washer 4
8 M10 X 20L SHC 4
40 Pad 1
4
8
40
Tighten M10 bolts to 57 N-m/29 ft-lbs.
