33
Cable tension is adjusted by raising or lowering pulley as shown.
Note: Nuts for adjustable pulley must be on inside towards weight plates.
ASSEMBLY
PART 11: CABLE ADJUSTMENT
Secondary hole is for additional cable tension adjustment if needed
Cable keeper must be positioned as shown
