Mazda 2008 CX-7 User Manual

89
Rear View Monitor
Variance Between Actual Road
Conditions and Displayed Image
Some variance occurs between the actual road and the displayed road. Such variance in
distance perspective could lead to an accident. Note the following conditions that may cause
a variance in distance perspective.
1 When the vehicle is tilted due to the weight of passengers and
load
When the vehicle rear is lowered, the object displayed on the screen appears farther than the
actual distance.
The figure is an example showing Mazda CX-9.
2 When there is a steep grade behind the vehicle
When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the
screen appears farther (downgrade: closer) than the actual distance.
The figure is an example showing Mazda CX-9.
Object
Variance
Appears
farther than
actual
distance
Appears
closer than
actual
distance
Object at actual position
Object at actual
position
Object on screen
Object on screen
A: Distance between the vehicle and object displayed on the screen.
B: Actual distance between the vehicle and object.
