McCulloch B28 PS User Manual

English--- 22
115432326 Rev. 4 2/17/12
MAINTENANCE
Bevel gear
The bevel gear is filled with the right quantity
of grease at the factory. However, before
using the machine you should check that the
bevel gear is filled three--quarters full with
grease.
The grease in the bevel gear does not nor-
mally need to be changed except if repairs
are carried out.

McCulloch B28 PS Specifications

General

Type	Brush cutter
Head type	Blade & nylon line
Handle type	D-loop handle
Product color	Black
Rotational speed	8000 RPM
Sound power level	114 dB
Fuel tank capacity	0.45 L
Vibration emission	4.4 m/s²
Engine displacement	28 cm³
Sound pressure level	100 dB
Cutting diameter (max)	25.4 mm
Power source	Gasoline

Weight and Dimensions

Weight	5500 g
