McCulloch B28 PS User Manual

English--- 4
115432326 Rev. 4 2/17/12
WHAT IS WHAT?
25
4
4
4
27
19
20
21
1
22
24
26
1. Blade 16. Primer bulb
2. Grease filler cap 17. Air filter cover
3. Bevel gear 18. Handle adjustment
4. Cutting attachment guard 19. Blade retainer nut
5. Upper shaft 20. Cupped washer
6. Lower shaft 21. Retaining washer
7. Loop handle 22. Dust cup
8. Throttle control 23. Trimmer head
9. Stop switch 24. Transport guard
10. Throttle lock--out 25. Hex wrench
11. Harness clamp 26. Wrench
12. Cylinder cover 27. Harness
13. Starter handle 28. J--handle
14. Fuel tank 29. Shaft coupling
15. Choke control 30. Operator’s manual
What is what?
6
2
10
11
8
17
22
1
3
9
12
16
14
15
13
18
23
30
28
5
29
7

McCulloch B28 PS Specifications

General

Type	Brush cutter
Head type	Blade & nylon line
Handle type	D-loop handle
Product color	Black
Rotational speed	8000 RPM
Sound power level	114 dB
Fuel tank capacity	0.45 L
Vibration emission	4.4 m/s²
Engine displacement	28 cm³
Sound pressure level	100 dB
Cutting diameter (max)	25.4 mm
Power source	Gasoline

Weight and Dimensions

Weight	5500 g
