:1 ~ 4 alarm settings in channel 1 ~ 4. For different channels, the same alarm need to set different
alarm value. User enabled via #600 ~ #603
1.5.6 Parameter save setting
The BFM parameter saving Settings of MTC-08-NT buffer (BFM) are shown in table 1-13
Table 1-13 save Settings for BFM parameters of MTC-08-NT buffer (BFM)
Module parameter saving*1
Default value: 0 (no
parameter saved)
1: parameter save start
* 1. #700: when the user save the parameter, and this position is 1, the module save the parameter set by
the current user. Operating instructions are as follows:
1) when #700 is set to 1, start the data backup. At this point, you need to wait for a few seconds before
the power is cut off, otherwise the parameter may be saved incorrectly. After MTC save the parameters,
#700 will automatically clear.
2) Parameter saving errors may occur when there are errors due to interference and temperature
controller. The parameters should be saved again. If the parameter is saved in error, the parameter will
be restored to the factory default value.
3) When there is a set value error, the original parameters of the unit will be saved.
1.5.7 Other
The rest of the buffer (BFM) of MTC-08-NT is shown in table 1-14
Other contents of the buffer (BFM) of table 1-14 MTC-08-NT
Module software version information*1
Thermostat identification code*2
* 1. #4094: module software version information.
* 2. #4095: module identifier. Ctc-04-nvt is identified by 0xB444. The user program in the programmable
controller can use this identifier in the program to confirm the thermostat before transmitting/receiving
data.
1.6 Attachment List
The terminal blocks supplied with the MTC-08-NT terminals are shipped with the terminal. The details are
shown in the table below.
Table 1-15 List of accessories
