340
Practical hints
Replacing bulbs
Replacing bulbs for rear lamps
Tail lamp assemblies
1 Backup lamp (black socket)
2 Turn signal lamp (white socket)
3 Tail, standing and parking lamp (red
socket)
4 Driver’s side: tail, parking and rear fog
lamp
Passenger’s side: tail and parking lamp
(red socket)
왘 Switch off lights.
왘 Open trunk.
왘 Turn lock counterclockwise and move
the trim to the side.
왘 Turn bulb socket counterclockwise and
pull out.
왘 Gently twist bulb counterclockwise and
pull out of bulb holder.
왘 Insert new bulb into the holder and turn
it clockwise.
왘 Reinstall bulb socket.
The bulb socket should audibly click.
왘 Replace trim and secure with lock.
License plate lamp
1 Screws
왘 Switch off the lights.
왘 Loosen both screws 1 and remove
lamp.
왘 Replace the tubular lamp and reinstall
it.
왘 Retighten the screws.
