Mercury 80 Owner's Manual

OUTBOARD INSTALLATION
75
FUEL HOSE CONNECTION
Fasten remote fuel hose to fitting with hose clamp.
Fuel Hose Size
Minimum fuel hose inside diameter (ID) is 8 mm (5/16 in.) with separate fuel hose/fuel tank pickup for each
engine.
a
b
20804
a - Hose clamp b - Fuel hose
SHIFT CABLE INSTALLATION
Install cables into the remote control following the instructions provided with the remote control.
NOTE: Install the shift cable to the engine first. The shift cable is the first cable to move when the remote control
handle is moved out of neutral.
1. Remove the access cover from the bottom cowl.
NOTE: The high pressure fuel hose can be moved out of the way for additional access.
a
b
20893
a - Access cover b - High pressure fuel hose
2. Position the shift mechanism into the neutral position.
