Mercury 80 Owner's Manual

OUTBOARD INSTALLATION
78
b
a
a
20905
a - Fuel hose retainer b - High pressure fuel hose
THROTTLE CABLE INSTALLATION
Install cables into the remote control following the instructions provided with the remote control.
1. Remove the access cover from the bottom cowl.
NOTE: The high pressure fuel hose can be moved out of the way for additional access.
a
b
20893
a - Access cover b - High pressure fuel hose
2. Position remote control into neutral.
N
ob00351
3. Install the throttle cable to the throttle arm with the retainer clip.
4. Adjust the cable barrel so that the installed throttle cable will hold the throttle arm against the idle stop.
5. Fit the throttle cable through the front grommet.
6. Place cable barrel into barrel retainer.
