5.
Lift the outboard and place it on the transom.
a -
Lifting base
b -
Lifting eye
Flywheel Puller/Lifting Ring
91‑895343T02
14869
Removes flywheel from engine. Used
for lifting powerhead/engine.
Shipping Bracket Removal
1.
Remove the two top screws and loosen the two bottom screws.
2.
Slide the shipping bracket off the bottom screws.
a
b
53797
OUTBOARD INSTALLATION
110
eng
119
