Section 2 - On the Water
90-8M0093150 eng MAY 2014 Page 17
Control Function
TRANSFER
Allows boat control to be transferred to a different helm. Refer to Helm Transfer.
DOCK
Available with joystick operation and the control levers.
• Joystick operation reduces throttle capacity to approximately 70% of normal joystick throttle
demand.
• Control lever operation reduces throttle capacity to approximately 50% of normal control lever
throttle demand.
THROTTLE ONLY
Allows the boat operator to increase engine RPM without shifting into gear. Refer to Throttle‑Only
Mode.
1 LEVER
Enables the throttle and shift functions of all engines to be controlled by the port lever. Refer to Single
Lever Mode.
SYNC
Turns the auto‑synchronization feature off or on. Refer to Synchronizing Engines.
+ (increase) and
– (decrease)
Increases and decreases brightness settings for the trackpad, VesselView display, and SmartCraft
gauges.
NOTE: On dash‑mounted DTS trackpads, these buttons increase or decrease the trolling speed.
Transfer (Boats Equipped with Dual Helms)
The transfer function allows the boat operator to transfer control of the boat from the active helm to the inactive helm on boats
equipped with dual helms. Refer to Helm Transfer.
Transfer button and light
Dock Mode
Dock mode reduces the RPM throughout the throttle lever range by 50%, allowing finer control of engine power in close‑quarter
situations. If more power is needed for vessel maneuvering when environmental conditions require more thrust, use the
electronic remote control levers.
NOTE: When the joystick is enabled, dock mode reduces available power to 70% of the already reduced power available with
the joystick.
To engage dock mode:
1. Place both ERC levers in neutral.
2. Press the dock button located on the DTS trackpad.
3. The dock light turns on.
4. Place either ERC lever into gear.
NOTE: Engine RPM and available power will be proportionately reduced throughout the throttle lever range.
Dock button and light
