PUMP SERVICE MANUAL NUMBER 23

Page 9A-8 90-861326--1 MARCH 1999

3. Remove mounting fasteners from pump.

72949

a-Nuts

4. Remove the power steering pump from the bracket.

75490

a-Power Steering Pump

b-Power Steering Bracket

5. Refer to appropriate Sterndrive Service Manual for power steering pump repair proce-

dures.
