SYSTEM TACH & SPEED
3-1
SYSTEM TACH & SPEEDOMETER
Tachometer Speedometer
0
1
2
34
5
6
7
0
10
20
30
40
50
60
70
80
Basic Operation and Features
Power up: Each gauge will power up when the ignition is turned on.
Gauges will stay on as long as the ignition is on.
Lights: The brightness and contrast are adjustable.
Buttons: The
MODE
button is used for selecting information screens.
The “+” and “–” buttons are used for setting engine speed during troll
control and setting gauge calibrations.
Troll Control: Allows the operator to set and control the idle speed
of the engine for trolling without using the throttle.
Engine Guardian System: Monitors the critical sensors on the engine
for any early indications of problems. The system will respond to a
problem by reducing engine speed in order to maintain a safe operat-
ing condition.
Warning System: The system will sound the warning horn and display
the warning message.
