Service Manual_2020-V1.0
32
1) Use a screwdriver to pry open the lamp cover;
2) Disconnect the terminal and remove the LED lamp.
Light on top of freezer compartment
1） Toplight of freezer is located at the bottom of the
greenhouse door. Use a screwdriver to pry the lamp
cover;
2) Take the LED lamp panel from the card slot,
disconnect the wiring terminal and remove the LED lamp.
The variable temperature chamber top light is located at
the bottom of refrigerating left door, and the disassembly
method is the same as that of the freezer top light.
Light switchs of refrigerator
