Service Manual_2020-V1.0
42
Evaporator in refrigerating chamber
1）After removing the refrigerator air duct assembly, use
slotted screwdriver to unlock the plastic hook of fridge
evaporator.
2）Disconnect all connecting terminals.
3）Remove the welding on inlet and outlet tubes.
4）Remove the evaporator to change a new one.
Evaporator of ice maker in refrigerating chamber
1) After power failurue and removing the refrigerator air
duct assembly, use slotted screwdriver to unlock the
plastic hook of fridge ice maker evaporator
2) Disconnect all connecting terminals
3) Remove the welding on inlet and outlet tubes
4) Remove the evaporator.
Defrost heater on the evaporator
