Hang the air-in grill to the panel, then connect
the lead terminator of the swing motor and that
of the control box with corresponding
terminators on the body respectively.
Install the 4 corner covers back.
Note: The panel shall be installed after the
wiring connected.
14.2.6 HESP duct indoor unit installation
14.2.6.1 Service space for indoor unit
500mm or more
600mm or more
Indoor unit
600mmx600mm
Maintenance and repair space
14.2.6.2 Bolt pitch
14.2.6.3 Install the pendant bolt
Select the position of installation hooks
according to the hook holes positions showed
in upper picture.
Drill four holes of Ø12mm, 45~50mm deep at
the selected positions on the ceiling. Then
embed the expansible hooks (fittings).
14.2.6.4 Install the main body
Make the 4 suspender through the 4 hanger of
the main body to suspend it. Adjust the
hexangular nuts on the four installation hooks
evenly, to ensure the balance of the body. Use
a leveling instrument to make sure the
levelness of the main body is within ±1°.
