MCAC-UTSM-201606 Midea 50Hz AC Fan Coil Unit Two-pipe Wall-mounted Series
- 44 -
to the Air Conditioner. Then after approximately another 2 seconds, the set temperature will re-appear on the
digital display.
3. Set the STARTING & STOPPING time
1) Please press the CANCEL button to cancel any former settings.
2) Push the TIMER button and the remote controller will show the last setting time for START operation and the
signal "h" will be shown on the display panel. You are now ready to readjust the TIMER ON to start the
operation.
3) Push the TEMP button ( or ) to set the time you want to start the operation.
4) Push the TIMER button and the remote controller will show the last set time for STOP operation and the signal
"h" will be shown on the display panel. You are now ready to reset the time of the STOP operation.
5) Push the TEMP button ( or ) to set the time you want to stop the operation.
6) After setting the TIMER there will be a one-half second delay before the remote controller transmits the signal
to the Air Conditioner. Then, after approximately another 2 seconds ,the set temperature will re-appear on the
digital display.
Notes:
1. Please reset the TIMER after cancelling the former time settings.
2. The setting time is relative time. That is the time set is based on the delay of the current time.
14.2 Optional Controller
14.2.1 Wired Controller KJR-10B
Name and Function of LCD display on the controller
