Midea 50Hz AC Fan Coil Unit Two-pipe Wall-mounted Series MCAC-UTSM-201606
- 5 -
6. Specifications
Model
MKG- 250 300 400
Air flow
H/M/L m
3
/h 425/360/320 510/430/380 680/580/510
H/M/L CFM 250/210/190 300/250/220 400/340/300
Cooling
Capacity H/M/L kW 2.2/1.84/1.65 2.64/2.24/2.05 3.08/2.62/2.27
Water flow rate H L/h 378 454 530
Water pressure drop H kPa 12 18 22
Heating
Capacity H/M/L kW 3.02/2.6/2.23 3.69/3.25/2.77 4.34/3.86/3.25
Water pressure drop H kPa 10 16.4 20.8
Power supply
V/Ph/Hz
220-240/1/50
Power input
H W 28 40 44
Sound pressure level
H/M/L dB(A) 30/24/20 35/29/24 37/31/26
Fan motor
Type Low noise 4-speed fan motor
Quantity 1
Fan
Type Cross-flow fan
Quantity 1
Coil
Row
2
Max. Working pressure MPa 1.6
Diameter mm Φ7
Body
Dimensions W×H×D mm 915×210×290
Net weight kg 12
Packing W×H×D mm 1020×300×385
Gross weight kg 16
Pipe
connection
Water inlet/outlet pipe inch G3/4"
Drain pipe mm ODΦ20
Controller
R51/E (standard)
Notes:
1. H: high fan speed; M: medium fan speed; L: low fan speed
2. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°C WB.
Heating Conditions: Entering Water 50°C, Enter air temperature 20°C, and water flow is same to the cooling conditions.
3. Noise is tested in semi-anechoic test room.
