Technical data
54
Fan motor* 90 W
Hob lighting
DA 3566 2 x 4.5 W
DA 3596 3 x 4.5 W
Total connected load*
DA 3566 99 W
DA 3596 103.5 W
Voltage, frequency AC 230 V, 50 Hz
Fuse rating 5 A
Mains connection cable length 1.5 m
Weight
DA 3566 15 kg
DA 3596 18 kg
DA 3566 EXT 13 kg
DA 3596 EXT 16 kg
* For EXT models, the connected load will depend on the type of external motor fitted.
Length of connection cable to external motor: 1.9 m
Special accessories for recirculation mode:
Conversion kit DUU 150 or DUU 151 and Miele charcoal filter set DKF 19-1. Contains two
charcoal filters.
Conformity declaration
Miele hereby declares that the cooker hoods listed at the end of this booklet com‐
ply with the basic requirements and other relevant regulations of Guideline
1999/5/EC.
A copy of the full Declaration of Conformity can be obtained from the address at
the end of this booklet.
