Venting systems
The various venting systems which are
possible are described on the following
pages.
a Flexible ducting hose
b Plastic piping
c Connecting directly to a wall vent
a Flexible ducting hose
This is a simple, cost effective way of
directing the moist air outside. The
adapter supplied is fitted into the
vent opening on the dryer and the
100 mm C ducting hose is then
connected to the adapter.
^
The following items are required: . .
. . . flexible ducting hose
...awall vent kit* or window vent
kit*.
* (Miele optional accessory).
A Insert adapter (1) into the vent
opening on the dryer.
B Attach the hose (2).
^
Installation examples are shown on
the next page.
Installation - venting
38
